Healthcare Door

UL listed fire doors for healthcare facilities
SAMEKOM specialize in designing and customizing turn-key doors solution for healthcare facilitis ,hospital ,medical centers ect with durability and excellent patience experience.
  • Product Details

SAMEKOM has been supplying and customizing affordable doors for many healthcare buildings ,both functionally and architecturally.

-3/4’’ (45mm)Thick steel doors shall be manufactured by SAMEKOM Door shall be confirm to GB/T 20909-2007”Steel Door and Window” standard. The WH and UL approved door will also refer to  Steel Door Institute guide specification for design ,see chart below for performance classifications .

Standard configuration

Door leaf:        45mm

Sheet thickness 0.9 ~1.2mm

Frame:             vary from 128~158mm

Sheet thickness 1.4mm                          Stainless steel threshold (as request)

Welded grouting lugs /anchor brackets

Surface finish:             Door leaf and frame galvanized and powder coated with a primer

Hinges:             butterfly hinge with ball bearing

Healthcare door Lock:                Mortice lock with lever /knob

Panic bar with cylinder                            Panic bar handle

Deadlock insert with key                            Fixed leaf with bolt (locking to top and bottom)

Healthcare doors hardware set :       Fire-proof round handle/lever handle set in stainless steel  Can be used for profile cylinder and deadlock key

Closing device: Overhead door closer with lifting arm Bolts:                 2 steel bolts for double leaf door Fitting to :          Masonry wall                            Concrete wall                            Dry wall

healthcare UL fire door
